S118HII 18 inch subwoofer
Applications
- Touring performance
- Stadium
- Theatre
Feature
- 100mm voice coil, high transient response woofer
- Thick and elastic hearing
- Vented, horn preposition design
Technical Specification
| Parameter Name | Parameter Value |
|---|---|
| FREQUENCY RESPONSE | 30 Hz-180 Hz (±3 dB), 25 Hz-250 Hz (-10 dB) |
| NOMINAL COVERAGE (±6dB) | Omnidirectional |
| SENSITIVITY (@1W/1m) | 100 dB SPL |
| POWER RATING (AES) | 1200W |
| NOMINAL IMPEDANCE | 8 ohm |
| MAXIMUM SPL | 130 dB (continuous), 136 dB (peak) |
| DRIVERS | 1x 18″ (100mm voice coil) subwoofer |
Physical Data
| Parameter Name | Parameter Value |
|---|---|
| Dimensions (HxWxD) | 750 x 561 x 880 mm / 30″x22″x35″ |
| WEIGHT | 48 kg / 106 lbs |
| CONNECTORS | 2 x NL4 connectors |
| SPEAKER CABLES | 1+1- |
| MATERIALS | 18mm, 24mm, 30mm Baltic birch plywood |
| FINISH | Black Polyurea paintings |
| GRILLE | Black epoxy mesh grille with acoustically reticulated cloth |
| ASSEMBLY | 4 handle cups, 4 rigging, M20 jacking |
