VCSUB
21 inch subwoofer speaker
- 135mm voice coil for deep 25Hz bass.
- Flexible hanging/wiring for cardioid setups.
- Ideal for touring, stadiums, and theaters.
Applications
- Touring performance
- Stadium
- Theatre
Features
- Large 135mm voice coil, low frequency down to 25Hz
- Versatile hanging (3-point) and wiring (NL4 plug) options
- Neodymium high-sensitivity driver for maximum headroom
Technical Specifications
| Parameter | Value |
|---|---|
| Frequency Response | 30Hz–150Hz (±3dB), 25Hz–200Hz (-10dB) |
| Nominal Coverage (-6dB) | Non-directional |
| Sensitivity (@1w/1m) | 97dB SPL |
| Power Rating (AES) | 1800W |
| Nominal Impedance | 8 ohm |
| Maximum SPL | 129/135dB SPL peak |
| Drivers | 1×21” (135mm voice coil neodymium woofer) |
Physical Data
| Parameter | Value |
|---|---|
| Dimensions (HxWxD) | 590 x 1030 x 674 mm |
| Weight | 84 kg |
| Connectors | 2×4 WP4, 2×4 NL4 |
| Materials | 18mm/24mm birch plywood |
| Finish | Black polyurea paint |
| Grille | Black epoxy mesh |
