CP12
12 inch full range speaker
- Constant Directivity 80°×80° Coverage
- Extended Low Frequency Response (Down to 45Hz)
- High-Performance 75mm HF Compression Driver
Applications
- Conference room
- Church fill system
Features
- 75mm HF compression driver
- Low frequency response extended to 0Hz
- Excellent vocal performance
Technical Specifications
| Specification | Details |
|---|---|
| Frequency Response (±3dB) | 60 Hz ~ 16 kHz |
| Frequency Response (-10dB) | 45 Hz ~ 18 kHz |
| Nominal Coverage (-6dB) | 80°(H) × 80°(V) Constant directivity |
| Sensitivity (@1w/1m) | 97 dB SPL |
| Power Rating (AES) | 400W |
| Nominal Impedance | 8 ohm |
| Maximum SPL | 123dB SPL, 129dB SPL peak |
| Drivers | LF: 1×12″ driver HF: 1×3″ (75mm voice coil) compression driver |
Physical Data
| Specification | Details |
|---|---|
| Dimensions (H×W×D) | 480×370×370mm (18.9″×14.6″×14.6″) |
| Weight | 22kg (48.5lbs) |
| Connectors | NEUTRIK NL4MP×2 |
| Speaker Cables | 1+1- |
| Materials | 15mm, 18mm multi-plywood |
| Finish | Black polyurea paintings |
| Grille | Black epoxy mesh grille with acoustically reticulated foam |
